JX021 Flexible Straw Making Machine

Description

021 Flexible Straw Making Machine is one of the corollary equipment of 01 series Straw Extrusion Line, used to bend the straight PP/Paper/PLA straws to be flexible with corrugated shape.

Characteristics

Stable running, can continuously work for long time;
Automatic counting & Batch alarm function is available;
Machine stop automatically when fault.

Category Plastic Manufacturing Product ID: 58617

Product Description

Model	JX021
Power supply	1.5kw
Capacity	200–300 pcs/min
Specification Of Straw	Inside diameter	Φ3.8	Φ4.8	Φ5.8
	Length of straight straw	165–245 mm	200–260 mm	200–260 mm
	Thickness of straw	0.12–0.2 mm	0.12–0.2 mm	0.12–0.2 mm
	Length of finished straw	150–230 mm	185–245 mm	185–250 mm
	Top section length	35–50 mm
	Machine dimension (L × W × H)	1.5 m × 1.8 m × 1.7 m
Weight	1000 kg
