JX026 High Speed Flexible Straw Making Machine
Description
026 High Speed Flexible Straw Making Machine is one of the corollary equipment of 01 series Straw Extrusion Line, and the upgrade machine of JX021. It is used to bend the straight straws to be flexible with corrugated shape.
Characteristics
- High efficiency with stable running performance;
- Automatic counting&Batch alarm function is available;
- Machine stop automatically when fault.
Product Description
| Model | JX026 | |||
|---|---|---|---|---|
| Power supply | 2.2kw | |||
| Production Capacity | 500-700pcs/min | |||
| Specification Of straw | Inside diameter | Φ6 | Φ8 | Φ10 |
| Length of straight straw | 200-260mm | 200-260mm | 200-260mm | |
| Thickness of straw | 0.18-0.22±0.02 | 0.18-0.22±0.02 | 0.18-0.22±0.02 | |
| Length of flexible straw | 185-245mm | 185-245mm | 185-245mm | |
| Top section length | 30-50mm, customized | |||
| Machinery dimension L×W×H | 2.4m×1.3m×1.6m | |||
| Weight | 1T | |||
Consult your machining problems and needs. More Information about product, detail specification, etc..
